Sample laminated brass shim for the aerospace industry
Sample Laminated Brass Shim Stock Shims
Overall Part Dimensions: 3" X 3" X .04"
Primary Process: Press / Shearing / CNC Machining / Drilling / Milling
Secondary Process: Deburring / Outside Processing / Part Marking / Final Quality Assurance
- Length: 3"
- Width: 3"
- Thickness: 0.04"
- Tightest Tolerances: +/- 0.002"
- Material: Laminated Brass Shim Stock
- Testing: In Process Inspection: / Final QA / FAIR
- Production Volume: 50
| Primary Process | Press, Shearing, CNC Machining, Drilling, Milling |
|---|---|
| Secondary Process | Deburring, Outside Processing, Part Marking, Final Quality Assurance |
| Overall Part Dimensions | 3" X 3" X .04" |
| Length | 3" |
| Width | 3" |
| Thickness | 0.04" |
| Tightest Tolerances | +/-0.002" |
| Material | Laminated Brass Shim Stock |
| Testing | In Process Inspection, Final QA, FAIR |
| Production Volume | 50 |
